4G Dashcam
Product Description:The DC102 4G Dashcam is a comprehensive automotive active safety solution that integrates satellite positioning, video surveillance, and other functionalities. This product complies with national standard protocols such as JT/T808, JT/T905, and JT/T1078, meeting the requirements for video surveillance management and standardized driving behavior enforcement in ride-hailing services, taxis, and logistics fleets.
Detail:
 |
2K HD Recording |  |
140° Wide Angle | |||
 |
Live Video Streaming |  |
DC9~36V Wide Voltage | |||
 |
Driver Safety Alerts |  |
Voice Intercom | |||
 |
Support TF 512GB Max storage |  |
Remote Tracking & Route Replay | |||
 |
Emergency SOS |  |
Remote Upgrade & Configuration | |||
 |
Support Real-time Positioning |  |
Video and Track Playback | |||
 |
Support connection to multiple servers |  |
Hardware Watchdog Design |
Features:
The DC102 is a comprehensive automotive active safety solution that integrates satellite positioning, video surveillance, and other functionalities.
This product complies with national standard protocols such as JT/T808, JT/T905, and JT/T1078, meeting the requirements for video surveillance management and standardized driving behavior enforcement in ride-hailing services, taxis, and logistics fleets.
Specification:
| Function | Description |
| Position Function | Real-time GPS location tracking |
| Vehicle position report | |
| Historical route playback | |
| Recorder | Local video recording |
| Remote video viewing | |
| Alarm | Overspeed warning |
| Fatigue driving detection | |
| Emergency SOS alarm | |
| Parameters Query | Device status query |
| Remote parameter configuration | |
| Upgrade | Remote firmware upgrade |
| Multimedia | Photo capture |
| Video upload | |
| Video playback | |
| Audio & Video | Real-time video streaming |
| Remote video download | |
| Platform intercom |
| Item | Specification |
| CPU | ARM Cortex-A7@900MHz |
| RAM | DDR2 512Mb |
| Flash | 256 Mb EMMC |
| Operating System | Linux |
| Network | 4G LTE |
| Wi-Fi | Built-in SDIO module, 2.4 GHz frequency band, WIFI: IEEE 802.11 b/g/n, FPC antenna (with dedicated onboard antenna slot) |
| GPS | Built-in GPS |
| Power Supply | 12V(DC9-36V) |
| Working Temperature | -20°C to +70°C |
| Humidity | 10% to 90% Non-condensing |
| Net Weight | 134g |
| External Dimensions | 106mm*82mm*50mm |
| Platform Integration | JT/T808、JT/T1078 |
| Item | Specification |
| Video Format | H.264/H.265 |
| Audio Format | AAC/G.711A Compression Format |
| Built-in Speaker | Support |
| Built-in MIC | Support |
| Item | Specification |
| Resolution | 2K HD, 2560×1440 |
| Lens | Wide angle Lens |
| FOV | 118° field of view, 2G2P, 2.0 aperture |
| Frame Rate | 25FPS |
| Item | Specification |
| G-Sensor | Support |
| Storage | TF Card, Maximum support: 512 GB |
| SIM Card | Nano SIM |
Optional Accessories:
Vehicle Tracker
