GPS Tracking Device
Product Description:VT600 is a GPS/GPRS based tracking device, specially developed and designed for vehicle real-time tracking and fleet management. VT600 has an inbuilt GPS module to obtain accurate position data. This device utilizes its GSM capability to send position data to a specified mobile phone or server base for tracking and fleet management. With internal memory, VT600 can store GPS coordinates when there is no GPRS connection, or at a specified interval requested by the user. One optional feature of VT600 is that a microphone can be linked and hidden somewhere inside the vehicle for listening to the cabin.
Detail:
 |
Remote cut-off (petrol/power)
Compel the vehicle to stop by breaking off the fuel connection |
 |
Anti-Jammer (optional)
Resist GPS or GSM jammer to keep working and report to GPS tracking software |
|||
 |
1-Wire Interface
1-wire interface for temperature sensor/ ibutton (customized version) |
 |
Listen-in
Allows the caller to listen to what is happening around the tracker |
|||
 |
4MB Flash Memory
Store GPS coordinates when there is no GPRS connection, or at a specified interval requested |
 |
Smart Alarms
Movement alarm, low battery alarm, GPS blind area alarm, power-cut alarm, GPS antenna disconnect alarm and Geo-fencing alarm |
|||
 |
Multiple I/O Interfaces
Monitor and control external application via input/outputs |
 |
Tracked by: SMS, APP, WebReporting location in real-time through different interfaces |
Features:
VT600 is a GPS/GPRS based tracking device, specially developed and designed for vehicle real-time tracking and fleet management.
VT600 has an inbuilt GPS module to obtain accurate position data. This device utilizes its GSM capability to send position data to a specified mobile phone or server base for tracking and fleet management.
With internal memory, VT600 can store GPS coordinates when there is no GPRS connection, or at a specified interval requested by the user.
One optional feature of VT600 is that a microphone can be linked and hidden somewhere inside the vehicle for listening to the cabin.
Specification:
| Items | Specifications |
| Power Supply | 10.6V – 36V / 1.5A |
| Backup Battery | 500mAh |
| Normal power consumption | 55mA/h |
| Dimension | 65mm x 61mm x 26mm |
| Weight | 90g |
| Work time | 30 hours in power-saving mode and 7.5 hours in normal mode |
| Operating temperature | -20° to 65° C |
| Humidity | 5% to 95% Non-condensing |
| GPS Module | latest GPS SIRF-Star IV chipset |
| GPS Sensitivity | -159Db |
| GPS Frequency | L1, 1575.42 MHz |
| C/A Code | 1.023 MHz chip rate |
| Channels | 20 channel all-in-view tracking |
| Position Accuracy | 10 meters, 2D RMS |
| Velocity Accuracy | 0.1 m/s |
| Time Accuracy | 1 us synchronized to GPS time |
| Default datum | WGS-84 |
| Reacquisition | 0.1 sec., average |
| Hot start | 1 sec., average |
| Warm start | 38 sec., average |
| Cold start | 42 sec., average |
| Altitude Limit | 18,000 meters (60,000 feet) max |
| Velocity Limit | 515 meters/second (1000 knots) max |
| LED | 2 LED lights to show GPS/GSM status |
| Flash Memory | 4MB |
| Button | One SOS Button |
| Interface | 3 digital inputs (1 negative, 1 positive triggering and 1 input changeable)
1 analog input 1 output. |
Optional Accessories:
Vehicle Tracker
